Home > Products > Heavy Duty Connector Insert > 10Pin 16A 830V Heavy Duty Connector Female Insert
10Pin 16A 830V Heavy Duty Connector Female Insert
  • 10Pin 16A 830V Heavy Duty Connector Female Insert10Pin 16A 830V Heavy Duty Connector Female Insert

10Pin 16A 830V Heavy Duty Connector Female Insert

OUKERUIO is a professional manufacturer. 10Pin 16A 830V Heavy Duty Connector Female Insert. We have the perfect design. High quality raw materials, high efficiency and competitive prices are what every customer wants. We can give you hard work with our team. We offer individual solutions and innovative products based on customer needs. And obtained a number of patents and certificates.

Send Inquiry

Product Description

OUKERUI is a professional China 10Pin 16A 830V Heavy Duty Connector Female Insert leader with high quality and reasonable price. In product design and production, the company has high-quality expertise at its core.Continuously absorb the world's most advanced industrial interconnection concepts and processes. Provide customers with high quality products.

Product Description

10Pin 16A 830V Heavy Duty Connector Female Insert is a Heavy Duty Connector manufacturer with TUV audit.We also have CE,UL,EAC certified high performance connectors. ISO quality management system. Patent configuration, easy installation, quick installation. Personalized interfaces for different scenarios. High quality raw material guarantee. Create more environmentally friendly products.

Basic Info.

 Model NO. HZW-HVE-010F
Contacts Surface Treatment Silver/Glod Plated
Housing Material Die-Casting Aluminum Alloy
Working Environments IP65 for Various Harsh Environments
Contact Cost Pay Additional Cost for Crimp Contacts
Specification CE, UL, ROHS
Origin China
Production Capacity 3000pieces Per Day
Certification UL
Contact Material Copper
Housing Coating Anti-Corrosion Powder Spray
Crimp Tooling Available
Transport Package Poly bag and Double Cartons
Trademark Oukerui
HS Code 8536900000

SPECIFICATION

Model No. HZW-HVE-010F
Terminal type Screw Terminal
Housings material Dia casting aluminum alloy
Working Voltage 830V
Rated Impulse Voltage 8KV
International protection(IP) grade IP65
Flammability V0
Mechanical Life Span Min 500 times
Warranty 1 Year
Gender type Female
Contacts' surface processing Silver or Gold Plated
Mounting type Bulkhead/Surface/ cable to cable
Insert Block Top grade PC
Working Current 16A
Temperature Bearing Range -40ºC~+125ºC
Pollution Degree 3
Transport packing Carton

SPECIFICATION OF CONTACT

Material Copper Alloy
Terminal Screw/Crimp Terminal
Screw terminal tightening 0.5Nm
Surface Treatment Silver/Gold Plated
Wire Gauge 1.0-2.5mm2(AWG18-14)
Stripping length 7-9mm

10Pin 16A 830V Heavy Duty Connector Female Insert are extensively used in equipment that require electrical and signal connections,such as mold ,machinery,construction machinery,textile machinery,transportation technology,electric energy,electric locomotives and so on various need electrical and petrochemical equipment.

Hot Tags: 10Pin 16A 830V Heavy Duty Connector Female Insert, China, Quality, Manufacturers, Suppliers, Factory, CE, UL, EUROMAP Standard
