24 Pin 16A 500V Heavy Duty Connector Female Insert
  • 24 Pin 16A 500V Heavy Duty Connector Female Insert24 Pin 16A 500V Heavy Duty Connector Female Insert
  • 24 Pin 16A 500V Heavy Duty Connector Female Insert24 Pin 16A 500V Heavy Duty Connector Female Insert

24 Pin 16A 500V Heavy Duty Connector Female Insert

You are welcomed to come to our factory to buy the latest selling, low price, and high-quality Oukerui 24 Pin 16A 500V Heavy Duty Connector Female Insert. The company has always been oriented by customer demand and respect for talents, constantly improve their strength, improve service level and quality. With many European and American, Asian and domestic customers, we have established long-term good relationship with common progress. Sincerely expect to join hands with you to create the future.

Send Inquiry

Product Description

High quality Oukerui 24 Pin 16A 500V Heavy Duty Connector Female Insert is offered by China manufacturer OUKERUI Buy 24 Pin 16A 500V Heavy Duty Connector Female Insert which is of high quality directly with low price.The number of Male inserts was 24, with 16A operating current and 500V operating voltage. The supporting housing and hoods are H24B.

Product Description

24 Pin 16A 500V Heavy Duty Connector Female Insert is a Heavy Duty Connector manufacturer with TUV audit.We also have CE,UL,EAC certified high performance connectors. ISO quality management system. Patent configuration, easy installation, quick installation. Personalized interfaces for different scenarios. High quality raw material guarantee. Create more environmentally friendly products.

Basic Info.

Model NO. HZW-HE-024F
Contacts Surface Treatment Silver/Glod Plated
Housing Material Die-Casting Aluminum Alloy
Working Environments IP65 for Various Harsh Environments
Contact Cost Pay Additional Cost for Crimp Contacts
Specification CE, UL, ROHS
Origin China
Production Capacity 3000pieces Per Day
Certification UL
Contact Material Copper
Housing Coating Anti-Corrosion Powder Spray
Crimp Tooling Available
Transport Package Poly bag and Double Cartons
Trademark Oukerui
HS Code 8536900000

SPECIFICATION

Model No. HZW-HE-024F
Terminal type Screw Terminal
Housings material Dia casting aluminum alloy
Working Voltage 500V
Rated Impulse Voltage 6KV
International protection(IP) grade IP65
Flammability V0
Mechanical Life Span Min 500 times
Warranty 1 Year
Gender type Female
Contacts' surface processing Silver or Gold Plated
Mounting type Bulkhead/Surface/ cable to cable
Insert Block Top grade PC
Working Current 16A
Temperature Bearing Range -40ºC~+125ºC
Pollution Degree 3
Transport packing Carton

SPECIFICATION OF CONTACT

Material Copper Alloy
Terminal Screw/Crimp Terminal
Screw terminal tightening 0.25Nm
Surface Treatment Silver/Gold Plated
Wire Gauge 1-2.5mm2(AWG26-14)
Stripping length 7-9mm

24 Pin 16A 500V Heavy Duty Connector Female Insert are extensively used in equipment that require electrical and signal connections,such as mold ,machinery,construction machinery,textile machinery,transportation technology,electric energy,electric locomotives and so on various need electrical and petrochemical equipment.
