3 Pin Heavy Duty Connector Male Insert
  • 3 Pin Heavy Duty Connector Male Insert3 Pin Heavy Duty Connector Male Insert

3 Pin Heavy Duty Connector Male Insert

OUKERUIO is a professional manufacturer3 Pin Heavy Duty Connector Male Insert. 3 Pin Heavy Duty Connector Male Insert have Perfect design high quality raw materials, high efficiency and competitive price are every customer's expectation.We can guarantee you the hard work of our team, we offer unique solutions and innovative products based on customer needs.

Send Inquiry

Product Description

As a professional manufacturer, we would be happy to give you a 3 Pin Heavy Duty Connector Male InsertWe offer you the best customer service and fast delivery. Heavy-duty connector spacers are available for printed industrial pins, multi-pole industrial connectors, CE and UL listed, factory supplied. Request a free quote now! Worldwide 1 day delivery online service.

Product Description

3 Pin Heavy Duty Connector Male Insertis a Heavy Duty Connector manufacturer with TUV audit.We also have CE,UL,EAC certified high performance connectors. ISO quality management system. Patent configuration, easy installation, quick installation. Personalized interfaces for different scenarios. High quality raw material guarantee. Create more environmentally friendly products.

Basic Info.

 Model NO. HZW-HVE-003-M
Contacts Surface Treatment Silver/Glod Plated
Housing Material Die-Casting Aluminum Alloy
Working Environments IP65 for Various Harsh Environments
Contact Cost Pay Additional Cost for Crimp Contacts
Specification CE, UL, ROHS
Origin China
Production Capacity 3000pieces Per Day
Certification UL
Contact Material Copper
Housing Coating Anti-Corrosion Powder Spray
Crimp Tooling Available
Transport Package Poly bag and Double Cartons
Trademark Oukerui
HS Code 8536900000


Model No. HZW-HVE-003M
Terminal type Screw Terminal
Housings material Dia casting aluminum alloy
Working Voltage 830V
Rated Impulse Voltage 8KV
International protection(IP) grade IP65
Flammability V0
Mechanical Life Span Min 500 times
Warranty 1 Year
Gender type Male
Contacts' surface processing Silver or Gold Plated
Mounting type Bulkhead/Surface/ cable to cable
Insert Block Top grade PC
Working Current 16A
Temperature Bearing Range -40ºC~+125ºC
Pollution Degree 3
Transport packing Carton


Material Copper Alloy
Terminal Screw/Crimp Terminal
Screw terminal tightening 0.5Nm
Surface Treatment Silver/Gold Plated
Wire Gauge 1.0-2.5mm2(AWG18-14)
Stripping length 7-9mm

3 Pin Heavy Duty Connector Male Insert are extensively used in equipment that require electrical and signal connections,such as mold ,machinery,construction machinery,textile machinery,transportation technology,electric energy,electric locomotives and so on various need electrical and petrochemical equipment.
